The SHFSG-RTR Output Router and Adder feature is designed for use cases in crosstalk compensation on superconducting qubit chips, simultaneous driving of multiple hyperfine transitions in color centers, performing state transfer protocols in quantum optics, and other experiments in which frequency multiplexing is needed.
The Output Router and Adder allows the user to flexibly route the signals generated by different Digital Signal Units (composed of the AWG cores and their associated digital modulation settings) to any front panel Output of the SHFSG+ Signal Generator. The same signal can be routed to multiple Outputs at once, and the user has independent amplitude and phase control of each routed instance of a signal. Taken together, this allows the Output Router and Adder to generate frequency multiplexed signals at the Outputs of the instrument, with independent frequency, phase, amplitude, and waveform properties for each frequency component.
The Output Router and Adder upgrade option introduces additional signal line connections between the different digital signal pathways that lead to the analog upconversion chains of the Outputs of the SHFSG4 and SHFSG8. On the SHFSG4, the Output Router and Adder increases the number of Digital Signal Units from 4 to 8. The Functional Diagram highlights how a signal can be routed from the Digital Signal Unit of Channel 2 to the Output of Channel 1.
